Technical Information
AATIS® and AATIS®/fr Aluminium Composite Panel
Premium quality architectural cladding material with superb durability and formability. AATIS® aluminium panel passed the European Coil Coating Association (ECCA) Standards and the American Architectural Manufacturer Association (AAMA) Standards. The Co-extrusion system guarantees bonding strength and a smooth, flat surface. The state of the art coating system with Kynar 500 ensures high weatherability and long lasting colour.
Surface Material
Standard Aluminium Alloy 3003/H16 or 3105/H16. Gauge = 0.5 mm (not including paint)
European Aluminium Alloy 3005/H42 or 5005/H42. Gauge = 0.5 mm (not including paint)
Coating System
| Top surface | -- Polyvinylidene Fluoride ( PVDF ) Kynar 500® PVDF. 70/30 or Hylar 5000 PVdF. FEVE Fluoropolymer,
Hign-tech Polymer-based Duragloss 5000, Continuose Anodized |
|
| -- PVDF 80/20 only with European Alloy 5005/H42 | ||
| -- 2 Coat System: 25μm* (+/- 3μm) | ||
| -- 3 Coat System: 30μm - 35μm* (+/- 3μm) | ||
| -- 4 Coat System: 30μm - 40μm* (+4/-2μm) | ||
| *depending on colour | ||
| Between Aluminium and Core | -- Chromate Coversion Coating | |
| Bottom surface | -- Polyester / Mill finished to prevent oxidation | |
| Adhesive Agent | -- OREVAC®. ARKEMA. Paris, France | |
| Protective Film | -- Polifilm®, Germany |
Core Material
| AATIS® | -- Non Toxic Low density Polyethylene | |
| AATIS®/fr | -- Non Combustible Mineral Filled Core. | |
| Magnesium Di-Hydrate. Apymag® 40, Germany. |
Material Code Tests: Thickness
AATIS®/fr:
| Panel Fire Test | -- DIN 4102 (Class B-1), BS 476 part 5, part 6, part 7, ASTM E119 (2 hr), ASTM E84 (Class A), ASTM E-108,
UBC 26-9, UL-94 (V-0) |
|
| Toxic Fumes Evaluation | -- ISO-TR 9122-3 / Lower than IDHL values limits |
| Thickness | -- 3 mm., 4mm., 5mm., 6mm. | |
| Standard Size | -- 1250mm. x 2440mm. x 4mm., and 1250mm. x 3200mm. x 4mm. | |
| Custom Size | -- Custom Width: 1000mm., 1300mm., 1350mm., 1500mm., 1575mm. (max) | |
| -- Custom Length: Up to 8000mm. | ||
| * Custom size are subjected to minimal order requirement and slightly longer delivery time | ||
| Warranty | -- up to 10 - 20 year Colour Warranty. | |
